Vector 14 white six-blade commercial ceiling fan01 / 03
Vector 14

Wide reach.
Quiet control.

Gyms, studios & polished commercial spaces

From$2,890Sample data
14 ft diameter
Up to 10,000 sq ft
10-year limited warranty

Ships in 3–5 business days
Exploded view of the Vector 14 motor, downrod and six-blade hub
1Commercial mounting system
20.9 kW direct drive
3Six aluminum blades
4Wall + app control
Vector 14 / Engineering

Wide reach.
Quiet control.

A balanced six-blade platform designed for polished commercial rooms.

Sample dataView complete specifications
0.9 kWsample direct drive
6 bladessample aluminum platform
IP55sample enclosure rating
Size and coverage

Commercial reach,
clearly planned.

Use these sample starting dimensions to check coverage and clearance before final sizing review.

Commercial gym used for Vector 14 sizing contextUp to 10,000 sq ft
14 ft diameter
Vector 14 six-blade fan dimension view
22–34 ft
sample mounting range
Project review
required

Vector 14 specifications

Motor
Direct drive
Blade platform
6 aluminum blades
Input power
0.9 kW
Airflow
Up to 285,000 CFM
Environment
Indoor
Protection
IP55
Sample data

Control and installation

Room-wide comfort,
clearly controlled.

Set speed, schedule operation and manage the room from the wall or app.

  1. 01Set fan speed
  2. 02Create a schedule
  3. 03Lock operator access
Vector 14 installed in a modern commercial gym
NORTHWIND
OFF
9:41 Vector 14

Current speed

3of 6
Schedule
Lock controls

What's in the box

Wall controller
Standard mount
Safety cable
Hardware kit
Installation guide
View installation resources Sample content
Vector 14 commercial ceiling fan installed above a modern gym
Commercial gym  |  Up to 10,000 sq ft
Sample data
Up to 10,000 sq ft22–34 ft mounting rangeProfessional sizing support
Built for active spaces

Move air.
Not
attention.

Comfortable circulation for gyms, studios and polished commercial interiors.

Quiet, balanced airflow that supports the room without competing with it.
Vector 14 application guideSample contentPlan your space
Before you buy

A few final details.

Start with clear ceiling height, room dimensions and overhead obstructions. Our airflow team can review your plan before purchase.

This sample configuration is shown for 208–240 V service. Final voltage and local electrical requirements must be confirmed before ordering.

The sample package includes the fan assembly, wall controller, standard mount, safety cable, hardware kit and installation guide.

Yes. Use the project quote route for volume pricing, coordinated delivery and a site-by-site fan layout review.
